Machining complexity
Lub hauv paus kom zoo dua ntawm -xav tau CNC machining yog lub siab tawv los ua qhov nyuaj uas lwm lub Hoobkas tsis kam lossis ua tsis tau. Peb muaj kev txawj ntse los tuav ntau yam nyuaj geometric nta thiab nyuaj rau txiav cov ntaub ntawv, kom ntseeg tau tus du ntawm koj cov tswv yim tsim.
Peb tuaj yeem ua tiav yooj yim:
- Cov kab noj hniav sib sib zog nqus (nrog rau qhov tob rau txoj kab uas hla ntawm qhov sib piv ntawm 15: 1)
- Ultra nyias phab ntsa siv (yam tsawg phab ntsa thickness 0.3mm)
- Micro aperture (qhov tsawg kawg nkaus txoj kab uas hla ntawm 0.2mm)
- Qhov chaw tsis sib xws thiab tsis muaj -dawb daim ntawv
Hais txog cov ntaub ntawv, peb tau sau cov kev paub dhau los hauv kev ruaj khov ntawm titanium alloys (TC4), Inconel, hardened steel (HRC{1}}), nrog rau siab -kev ua tau zoo engineering yas xws li PEEK thiab PPS. Rau cov ntaub ntawv nrog rau kev ua hauj lwm hnyav, peb txais cov cuab yeej tshwj xeeb txoj kev optimization, multi axis linkage ib -lub sij hawm clamping, thiab meej txias lub tswv yim kom zoo txo cov cuab yeej hnav thiab ib feem deformation.
5-axis CNC machining muaj qhov zoo tseem ceeb: feem ntau qhov nyuaj tuaj yeem clamped hauv ib qho mus, tiv thaiv kev rov ua dua qhov yuam kev thiab txhim kho qhov tseeb thiab ua haujlwm zoo.
Cov teeb meem nyuaj ntawm cov ntaub ntawv nthuav qhia (cov lus qhia pom zoo rau cov duab + cov lus piav qhia nyuaj):
Ib tus neeg siv khoom dav hlau tau thov kev ua haujlwm ntawm titanium alloy nyias- phab ntsa bracket, nrog phab ntsa tuab ntawm tsuas yog 0.4 hli thiab ntau qhov sib sib zog nqus kab noj hniav thiab lub kaum sab xis. Cov chaw tsim khoom qub tsis kam xaj vim muaj kev pheej hmoo deformation siab. Peb tau ua tiav entrusted lawv los ntawm 5-axis linkage thiab finite caij simulation tshuab, nrog kam rau ua tswj nyob rau hauv ± 0.008mm thiab tsis pom tseeb kev co qauv ntawm qhov chaw.
Sib piv Table of Processing Capability:
|
Hom Feature |
Peb Muaj peev xwm ua tau |
Kev lag luam Standard |
Advantage Description |
|
Nyias phab ntsa Thickness |
0.3mm ib |
Tshaj 0.8mm |
Txo qhov hnyav li 30% |
|
Deep Cavity Aspect Ratio |
15:1 |
8:1 |
Ua tiav hauv ib qho clamping |
|
Micro Qhov Diameter |
φ0.2 hli |
φ0.5 hli |
Haum rau precision kua qhov chaw |
|
Nto nyuaj |
5-axis freeform nto |
Feem ntau 3-axis |
Siab precision, 40% efficiency nce |
Nto & Zoo Zoo
Peb tsis tsuas yog tsom rau kev ua haujlwm raug, tab sis kuj tseem nyob ntawm qhov zoo ntawm qhov chaw tiav CNC. Txawm hais tias qhov chaw ua haujlwm, peb tsis ua haujlwm thiab ntim khoom raws li cov lus qhia tshwj xeeb kom paub tseeb tias xoom khawb shipping.
Nto roughness tswj: Nws tuaj yeem ruaj khov ua tiav tag nrho ntawm Ra 0.2 μ m (daim iav) rau Ra 3.2 μ m, thiab cov qauv milling tau tswj tau zoo los ntawm kev ua kom zoo ntawm cov cuab yeej txoj hauv kev thiab kev txiav.
Kev xaiv lwm txoj kev kho mob (thov nrog daim ntawv sib piv ua ntej thiab tom qab kev kho mob):
Anodizing:
Hom II qauv xim, Hom III nyuaj oxidation los txhim kho hnav tsis kam thiab corrosion kuj
01
Electropolishing:
iav nyhuv, tshem tawm micro burrs
02
Kev lag luam siab
Beam Blasting: Nruab nrab matte zoo nkauj
03
Hmoov txheej / ci xim:
Kev xaiv xim nplua nuj, khawb tsis kam
04
Electroless Nickel:
Nruab nrab plating, siab hnav tsis kam
05
Tag nrho cov khoom zoo li tau raug soj ntsuam nruj nruj cov qauv thiab AQL sampling soj ntsuam, thiab zoo li zoo machining yog peb qhov kev cog lus tseem ceeb.
Muaj Peev Xwm Ntau Lawm
Peb ntawm -xav tau kev pab cuam CNC machining muaj zog cov neeg siv khoom rhiab heev, seamlessly npog tag nrho cov kev xav tau los ntawm ib daim qauv mus rau loj- teev ntau lawm.
Khoom siv thiab txuj ci: Nruab nrog ntau tshaj 30 siab - CNC machining chaw, nrog rau ntau yam khoom siv tshuab 5-axis txuas. Qhov siab tshaj plaws ua tiav yog 800 × 600 × 500mm, thiab qhov tsawg kawg nkaus feature loj yog 0.2mm. Cov ntaub ntawv cov khoom lag luam npog ntau tshaj 20 feem ntau siv tshwj xeeb xws li aluminium alloy, stainless hlau, carbon steel, tooj liab, titanium alloy, engineering plastics, thiab lwm yam. Cov ntaub ntawv ib nrab yuav raug xa tawm hauv Tshuag.
Batch Sensitive xa khoom:
1-10 daim:
Prototype CNC machining, ceev tshaj tus me nyuam 1-3 hnub
10-500pcs:
Tsawg ntim CNC machining, ua tiav hauv 3-7 hnub
Ntau tshaj 500 daim:
Daim ntawv ntau lawm, ua haujlwm tau zoo, 7-15 hnub rau kev xa khoom
Txhua xyoo muaj peev xwm ntau tshaj 800000 daim. Tag nrho cov txheej txheem yog digitized heev: tom qab cov neeg siv khoom upload cov duab kos, AI pab cov lus hais tuaj yeem teb tsis pub dhau 24 teev thiab nkag mus rau theem noj sai tom qab kev pom zoo.
Txawm hais tias nws yog CNC machining ceev los yog loj - nplai noj, peb tuaj yeem ua tau raws li koj cov kev xav tau ntawm -kev tsim khoom xav tau nrog tus nqi zoo tshaj plaws thiab lub voj voog luv.
Certifications & Quality Assurance
Qhov kev lees paub zoo ntawm -xav tau CNC machining los ntawm peb cov ntaub ntawv pov thawj zoo thiab cov txheej txheem tswj xyuas nruj. Koj tuaj yeem tso siab rau peb nrog cov khoom muag.
Central certification system (kev pom zoo nrog daim ntawv pov thawj phab ntsa duab):
- ISO 9001: 2015 Kev Tswj Xyuas Zoo
- IATF 16949 Automotive Industry Quality Management System
- RoHS/REACH ib puag ncig ua raws li daim ntawv pov thawj
Cov txheej txheem tswj kom zoo:
Thawj Tshooj Kev Tshawb Fawb (FAI)
Kev soj ntsuam txheej txheem (IPQC)
Kev tshuaj xyuas tag nrho / kuaj kuaj (OQC) rau kev xa khoom
Kev ntsuas qhov tseeb ntawm kev sib koom tes ntsuas tshuab (CMM)
Cov neeg siv khoom tsis txaus siab tus nqi tau qis dua 0.3% hauv peb lub xyoos dhau los. Peb tuaj yeem muab cov ntaub ntawv ua tiav zoo xws li Daim Ntawv Pov Thawj Khoom Siv (MTC), Dimensional Inspection Report, PPAP file, thiab lwm yam raws li qhov yuav tsum tau ua.
Raws li ISO certified CNC machining thiab ntawv pov thawj CNC chaw tsim tshuaj paus, peb tau txais lub sij hawm ntev - kev ntseeg siab ntawm thoob ntiaj teb cov neeg muas zaub nrog quantifiable zoo cov ntaub ntawv.
